HELLA, 12V SPDT RELAY, WEATHERPROOF WITH BRACKET, 20/40A
- Nominal Voltage: 12V
- Rated Continuous Load: N/O 40A | N/C 20A at 85°C
- Ambient Temperature: -40°C...+125°C
- Contact Form: 1 Form C / SPDT
- Details
- Customers also bought
- Customer feedback
- Contact Material: AgSnO2
- Operating / Drop out Voltage: ≤ 8.0 V / ≥ 1.0 V
- Max.Coil Voltage: 16V
- Coil Resistance: 85 Ohm ± 10% (excluding suppression component)
- Suppression: Resistor, 680 Ohm
- Mechanical Cycles: 10,000,000
- Operating / Releasing Time: ≤ 10 ms / ≤ 10 ms
- Dielectric Strength: ≥ 1000 VDC
- Max. Inrush Load: 150A
- Resistive Load / Switching Cycles: N/O 40A | N/C 20A , 150,000 cycles
- Inductive load / Switching Cycles: N/O 30A | N/C 20A , 100,000 cycle
- Lamp Load (capacitive) / Switching Cycles: N/O 30A | N/C 20A , 100,000 cycle
- Vibration: 20 – 200 Hz, 50 m/s_, 6 h per axis
- Mechanical Shock: 500 m/s_, 11 ms, period: 1 min, 1000 times
- IP Rating: IP54 DIN IEC 60 529
-
